Stone Foundation Underpinning Winnipeg

stone foundation underpinning winnipeg

At Assured Piling, we specialize in stone foundation underpinning in Winnipeg, offering homeowners and property managers reliable solutions for aging or unstable stone foundations. With Winnipeg’s freeze-thaw climate and expansive clay soil, older homes with stone or rubble foundations are especially vulnerable to settling, bowing, or water intrusion. Our expert underpinning services are tailored to address these issues with long-lasting results.

Whether you’re restoring a heritage property, reinforcing a century-old home, or simply dealing with a sinking stone foundation, our team has the tools, knowledge, and experience to stabilize and preserve your building’s integrity—safely and affordably.

What Is Stone Foundation Underpinning?

Stone foundations—common in Winnipeg homes built before the 1950s—were often constructed using local fieldstone, limestone, or granite bonded together with lime mortar. While beautiful and historically significant, these foundations were never designed to handle modern load-bearing demands or soil movement caused by frost heave and hydrostatic pressure.

Underpinning is the process of strengthening an existing foundation by extending its depth or breadth to better distribute the load and resist future movement. For stone foundations, underpinning often involves:

  • Excavating sections beneath the existing foundation in stages

  • Pouring concrete footings or piers to stabilize weak sections

  • Repointing or replacing failing mortar joints

  • Applying waterproofing, insulation, or drainage improvements

  • Supporting walls using steel beams or screw piles when necessary

At Assured Piling, we use only engineer-approved methods and build to current building code standards to ensure your stone foundation is stronger and more resilient than ever.

Why Stone Foundations Settle in Winnipeg

Winnipeg’s geology and climate pose unique challenges for older buildings with stone foundations. Common causes of foundation issues include:

1. Clay Soil Movement

Winnipeg’s clay-rich soil expands when wet and contracts when dry, causing seasonal ground shifts. These repeated movements can create gaps beneath stone footings and cause uneven settlement.

2. Frost Heave

During winter, moisture in the ground freezes and expands, lifting parts of the foundation. When the frost thaws, the ground contracts again, leading to cracks and misalignment.

3. Poor Drainage

Old homes often lack modern weeping tile or sump pump systems, allowing groundwater to pool around foundations. This leads to erosion, hydrostatic pressure, and mortar deterioration.

4. Deteriorated Mortar

Stone foundations often used soft lime-based mortar that breaks down over time. As mortar weakens, individual stones can shift, creating bulges, cracks, and bowing walls.

If your stone foundation is experiencing cracks, sinking floors, sticking doors, water intrusion, or visible stone movement, it may be time to explore underpinning options in Winnipeg.

Signs You Need Stone Foundation Underpinning

If your home has a stone or rubble foundation, look out for these red flags:

  • Vertical or stair-step cracks in the basement wall

  • Inward bowing or bulging stone walls

  • Water leaking through mortar joints

  • Gaps between the wall and floor or ceiling

  • A musty basement smell from poor waterproofing

  • Sloping floors or misaligned doors upstairs

  • Evidence of mortar dust or crumbling joints

Our team will conduct a full site inspection to determine if stone underpinning, foundation wall stabilization, or full replacement is needed. We provide detailed quotes, engineer-approved drawings (if required), and a clear action plan.

Our Stone Foundation Underpinning Process

We tailor every underpinning project to the specific condition of your stone foundation and the goals for your property. Our standard process includes:

1. Site Inspection and Soil Evaluation

We assess structural stability, inspect mortar condition, and determine the extent of settling or movement. If required, a structural engineer or geotechnical consultant will be involved.

2. Permits and Preparation

We handle all necessary permits and utility locates before excavation begins. Interior supports may be added if extensive structural work is needed.

3. Excavation in Stages

We dig beneath the stone wall in 3–4 foot sections (to preserve wall stability), install rebar cages, and pour new concrete footings under the existing wall.

4. Mortar and Wall Repairs

We repoint or replace deteriorated mortar, reset shifted stones, and fill any wall cavities that reduce load-bearing capacity.

5. Waterproofing and Drainage

Where needed, we apply exterior waterproof membranes, install weeping tile, and add sump pump systems to protect against future water damage.

6. Backfilling and Restoration

Once the work is complete, we carefully backfill, grade the soil away from the house, and clean up the job site.

Underpinning Heritage Homes in Winnipeg

Many older homes in Winnipeg’s Crescentwood, Wolseley, Norwood Flats, and St. Boniface neighbourhoods have original stone foundations. These homes are full of character—but require special care.

We work with homeowners, engineers, and heritage consultants to preserve historical integrity while upgrading structural safety. We offer discreet underpinning and interior reinforcement to minimize the visual impact on heritage homes. Our goal is to preserve the beauty of your home—while ensuring it stands another 100 years.

Why Choose Us?

We are a locally owned company that understands Winnipeg’s foundation challenges better than anyone. When it comes to stone foundation underpinning in Winnipeg, we offer:

  • ✅ Over 20 years of combined local experience

  • ✅ Licensed and insured foundation repair contractors

  • ✅ Engineer-approved underpinning systems

  • ✅ Honest estimates and transparent communication

  • ✅ Deep respect for heritage structures

  • ✅ Affordable options for homeowners

  • ✅ Quality workmanship backed by warranty

We’re not a franchise or out-of-town crew—we’re your neighbours. We’ve worked on homes like yours. And we’ll treat your property like our own.

Our Related Services

In addition to stone foundation repair and underpinning, we offer complementary services such as:

  • Concrete foundation crack repair Winnipeg

  • Basement waterproofing Winnipeg

  • Foundation wall stabilization

  • Helical piles installation

  • Basement underpinning and foundation lowering

  • Mobile home underpinning near me

  • Cheap mobile home skirting and trailer underpinning in Winnipeg

  • Mobile home skirting installer for insulated skirting systems

If you’ve been Googling terms like “stone foundation repair Winnipeg”, “underpinning stone walls near me”, or “how to stabilize a stone foundation”, you’ve come to the right place.

Areas We Serve

We proudly serve all of Winnipeg including:

  • River Heights

  • Transcona

  • North Kildonan

  • Charleswood

  • Elmwood

  • St. Vital

  • Fort Garry

  • St. James

We also offer stone foundation underpinning services in nearby towns such as:

  • Steinbach

  • Headingley

  • Niverville

  • Stonewall

  • Selkirk

  • Oak Bluff

  • East St. Paul

  • West St. Paul

If you’re searching for stone foundation underpinning near me, give us a call.

Get a Free Estimate Today

Stone foundation issues won’t fix themselves—and waiting too long can lead to higher costs or unsafe living conditions. Let Assured Piling inspect your foundation and provide a long-term solution.

📧 info@winnipegpiling.ca

Request your free on-site assessment today and find out why so many homeowners trust Assured Piling for their foundation underpinning needs.
